FLEX 1U SERIES description...
| No | Form Factor | Part Number | watts | +3.3V | +5V | +12V | -12V | +5Vsb | Fan Size | Dimension | +3.3 +5V Max.Combined power | |
| 1 |
 |
1U | HF1U-400W001 | 400W | 16 | 16 | 32 | 0.3 | 2 | 4020 | 205*100*40.5MM | 90W |
| 2 |
|
1U | HF1U-450W001 | 450W | 18 | 18 | 36 | 0.3 | 2 | 4020 | 205*100*40.5MM | 100W |
| 3 |
|
1U | HF1U-500W001 | 500W | 20 | 20 | 40 | 0.3 | 2 | 4020 | 205*100*40.5MM | 110W |
| 4 |
|
1U | HF1U-550W001 | 550W | 22 | 22 | 40 | 0.3 | 2 | 4020 | 205*100*40.5MM | 110W |
| 5 |
|
1U | HF1U-600W001 | 600W | 24 | 24 | 44 | 0.3 | 2 | 4020 | 205*100*40.5MM | 120W |
