ATX powers are an industrial and commercial level of switching power supply. The power supply comes to offer the total power capacity up to 1000 Watts, and uses unique active PFC (Power Factor Correction) circuit design with its high-load electrical components, makes it to be perfectly used in an industrial environment. In addition, with its full range of input and output electrical features, the power supply is ideally the best choice for server, workstation, communication or any other automation applications to use. The product also complies with the latest safety and EMC standards, which is perfectly to meet various regulations worldwide.
APPLICATION
For standard, advanced workstation, server and industrial power system.
FEATURES
80 85 88 Plus
Low Ripple & Noise
Output over voltage protection
Short circuit protection on all outputs
Resettable power shut down
GENERAL SPECIFICATION
Effciency: 78% 230VAC
Voltage Regulation: +3.3V, +12V, +5V, +5SB: ±5% -12V: ±10%
ENVIRONMENTAL SPECIFICATION
TEMP.Range: Storage Temperature: -20°C to + 80℃
MTBF: The power supply have a minimum predicted MTBF(MIL-HDBK-217) of 100,000 hours of continuous operation at 25℃,maximum-output load
|
No |
Form Factor |
Part Number |
watts |
+3.3V |
+5V |
+12V |
-12V |
+5Vsb |
Fan Size |
Dimension |
+3.3 +5V Max. Combined power |
图片 |
|
1 |
ATX 12V |
HF01-300W001 |
300W |
20A |
20A |
17A |
0.5A |
2.0A |
120 |
140*150*86 |
90W |
 |
|
2 |
ATX 12V |
HF01-350W001 |
350W |
20A |
20A |
21A |
0.5A |
2.0A |
120 |
140*150*86 |
90W |
|
|
3 |
ATX 12V |
HF01-400W001 |
400W |
20A |
20A |
25A |
0.5A |
2.0A |
120 |
140*150*86 |
90W |
|
|
4 |
ATX 12V |
HF01-450W001 |
450W |
20A |
20A |
30A |
0.5A |
2.0A |
120 |
140*150*86 |
90W |
|
|
5 |
ATX 12V |
HF01-500W001 |
500W |
20A |
20A |
34A |
0.5A |
2.0A |
120 |
140*150*86 |
90W |
|
|
6 |
ATX 12V |
HF01-550W001 |
550W |
20A |
20A |
38A |
0.5A |
2.0A |
120 |
140*150*86 |
90W |
|
|
7 |
ATX 12V |
HF01-600W001 |
600W |
20A |
20A |
42A |
0.5A |
2.0A |
120 |
140*150*86 |
90W |
|
